Aerial Work Platform Type XG0807HD-XG0807HDW is developed by XCMG, Lifter or Scissor Lift Hydraulic Drive uses an electric motor drive system which is more compact because it only uses one motor for maneuvering and lifting, this scissor lift is more effective and energy efficient featuring zero emissions and low noise. The working height is 8 m, the vehicle width is 0.76m, the rated load is 230kg, and max. gradability is 25%. This vehicle features a compact structure, advanced performance, and completed safety devices, specially suitable for construction. In addition. It is free of any pollution, with steady lifting/lowering, easy control, and maintenance. Therefore, these kinds of platforms are widely applied to warehouses, factories, airports, train stations, and especially narrow spaces.
Specification:
- Working Height: 7.8 Meters
- Platform Height: 5.8 Meters
- Load Capacity: 230 Kg
- Power Source: Maintenance-Free Lead-Acid Battery (280 Ah / 24 DC)
Product performance advantages and characteristics :
The effective and energy-saving electric-drive system features zero-emission and low noise, together with the traceless tires, easily enabling this machine to work in enclosed environments such as office buildings, hospitals, and schools and minimizing the effect on the environment.
An active protective mechanism such as pit protection and the self-developed safety control system features a humanized design and rich options, meeting the customer needs for safety, reliability, and intelligence. The working platform is able to extend out, enlarging the workspace, together with the foldable fence making transportation easier.
"Zero Turning Radius" is unique and enables the machine to corner in a narrow room.
Load capacity is 230kg, leading the industry.
Maximum traveling speed is 4km/h and gradability is 25% makes driving much easier.
